Three-way ball valve: L shape (Q44F), T shape (Q45F)
Three-way ball valve: L shape (Q44F), T shape (Q45F)
VGZ Three-way ball valve: L shape (Q44F), T shape (Q45F)
| Describe： |  |
|||||
| Three-way ball valves can be divided into L-shaped and T-shaped. L-shaped (Q44F) three-way ball valves are used to switch the direction of medium flow, which can connect two vertical channels. T-shaped (Q45F) three-way ball valves are used to divert, merge and switch the direction of medium flow. | ||||||
| Design features： | ||||||
| The ball valve are designed in accordance with ISO14313、API 6D、BS 5351、GB/T 19672; Simple structure with good sealing performance and small torque; Full bore and reduced bore design with the minimum flow resistance (zero actually); Emergency sealant injection; Cavity pressure self relief; Independent ball and stem; Low emission packing; Fire safe, anti-static and anti-blowout stem design; |
||||||
| Product Range： | ||||||
| Body material: carbon steel, stainless steel, alloy steel Nominal diameter:2"～48"（DN50~DN1200） End Connection: RF, RTJ, BW Pressure range: Class150～2500（PN16~PN420） Working temperature:-46℃～+200℃ Operation: Wrench, worm gear, electric, |
||||||
