Side mounted fixed ball valve (casting-2 pcs)
VGZ Side mounted fixed ball valve (casting-2 pcs) Q347F/Q347H
Describe：
Side-mounted fixed ball valves can be designed in three-piece and three-piece form, with two movable floating seats under medium pressure, with special springs at the bottom of the seat to ensure that the two seats are close to the sphere, and under the action of medium pressure, the ball-heel seat is pushed closer to ensure sealing.
Design features：
The ball valve are designed in accordance with ISO17292、API 608、BS 5351、GB/T 12237;
Simple structure with good tightness and small torque;
Have reduce bore type and full bore type with the minimum flow resistance (zero actually);
Low emission packing;
Fire safe, anti-static and anti-blowout stem design;
Optional locking device
Optional ISO 5211 top flange
Product Range：
Body material: carbon steel, stainless steel, alloy steel
Nominal diameter:2"～36"（DN15~DN900）
End Connection: RF, RTJ, BW, THR, SW
Pressure range: Class150 – 2500（PN16~PN420）
Working temperature: -46℃- +200℃
Operation : wrench, worm gear, electric, etc
